201 Carbon Steel Ball Valves
Care to learn more about our many ball valve solutions?
Contact our sales and support team today to discover your perfect ball valve solution!
-
CALL US
1 (877) 683-2200
-
EMAIL US
Western Gauge & Instruments (WGI) prides itself on being industry innovators in 201 Carbon Steel Ball Valves. By continually offering and using the latest in technology and measurement solutions, WGI has a long-standing reputation of providing top quality products using the best of materials and workmanship.
All WGI 201 Carbon Steel Ball Valves products are manufactured in an ISO 9001 Certified facility and have appropriate Canadian Registration Numbers (CRN) where applicable.
201 Carbon Steel Ball Valves
Product Description:
WGI ball valves combine quality performance at an affordable price. Each valve carries approvals that will cover most valve applications. These valves are used in different industries for a variety of applications.
Specifications:
Pressure Rating
• 1/4″ — 2″ 2,000 PSI
Porting
• Full port
Temperature Rating
• -40oF — 392oF (-40oC — 200oC)
Body Material
• ASTM A216-WCB
Approvals
• NACE MR-0175, CRN * Seal Weld Ends
Features
• Blowing-Out Proof Stem, Locking
Our WGI 201 Carbon Steel Ball Valves have the following Product Specifications, Build of Materials, and Dimensions:
| SPECIFICATIONS | |
|---|---|
| Pressure Rating | 1/4″ — 2″ 2,000 PSI |
| Porting | Full port |
| Temperature Rating | -40° F — 392° F (-40° C — 200° C) |
| Body Material | ASTM A216-WCB |
| Approvals | NACE MR-0175, CRN * Seal Weld Ends |
| Features | Blowing-Out Proof Stem, Locking Handle, Tapped and Drilled Mounting Pad |
| MATERIAL | ||
|---|---|---|
| Item | Parts | Material |
| 1 | Body | ASTM A216 – WCB |
| 2 | Cap | ASTM A216 – WCB |
| 3 | Ball | ASTM A351 – CF8M |
| 4 | Stem | ASTM A276-316 |
| 5 | Gland Nut | AISI 304 |
| 6 | Seat | PTFE / RTFE |
| 7 | Seal | PTFE |
| 8 | Packing | PTFE / RTFE |
| 9 | Thrust Washer | PTFE |
| 10 | Spring Washer | AISI 304 |
| 11 | Nut | AISI 304 |
| 12 | Handle | Stainless Steel |
| 13 | Handle Sleeve | PVC |
| 14 | Locking Device | AISI 304 |
| DIMENSIONS | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NPS | D | L | L1 | H | W | H1 | H2 | H3 | S | M | E | T | Weight(lb) |
| 1/4″ | 0.46 | 2.38 | 0.55 | 1.97 | 4.02 | 0.91 | 0.63 | 0.41 | 0.20 | M5 | 1.10 | 5/16″ W | 0.6 |
| 3/8″ | 0.51 | 2.38 | 0.55 | 1.97 | 4.02 | 0.91 | 0.63 | 0.41 | 0.20 | M5 | 1.10 | 5/16″ W | 0.6 |
| 1/2″ | 0.59 | 2.52 | 0.55 | 1.97 | 4.02 | 0.91 | 0.67 | 0.41 | 0.20 | M5 | 1.10 | 5/16″ W | 0.7 |
| 3/4″ | 0.79 | 3.03 | 0.87 | 2.44 | 4.72 | 1.14 | 0.87 | 0.53 | 0.26 | M5 | 1.38 | 3/8″ W | 1.2 |
| 1″ | 0.98 | 3.54 | 0.87 | 2.97 | 6.26 | 1.34 | 0.94 | 0.61 | 0.31 | M5 | 1.38 | 7/16″ W | 1.9 |
| 1¼” | 1.26 | 3.94 | 0.94 | 3.19 | 6.26 | 1.34 | 0.97 | 0.61 | 0.31 | M5 | 1.54 | 7/16″ W | 2.8 |
| 1½” | 1.50 | 4.65 | 0.94 | 3.86 | 7.40 | 1.54 | 1.02 | 0.69 | 0.35 | M5 | 1.5 | 1/2″ W | 4.4 |
| 2″ | 1.97 | 5.43 | 0.94 | 4.25 | 7.40 | 1.54 | 1.02 | 0.69 | 0.35 | M5 | 1.5 | 1/2″ W | 6.9 |
| Thread Type: ASME B1.20.1 (NPT) | Dimensions: inch | |||||||||||||
Products Catalogue
from WGI
Download more in-depth technical specifications for our line of 201 Carbon Steel Ball Valves by clicking on any of the above literature thumbnails.
